Schulz 20 Cfm Compressed Air Refrigerated Air Dryer For 3hp And 5hp Air Compressor
S
USD $1,425.00
Condition : NEW
Free Shipping
{{variant_type_name}} :
Notify me when the price drops
We will email you if we find a lower price on this product!
- 20 CFM Schulz Heavy Duty Compressed Air Refrigerated Air Dryer
- 20 CFM @ 100 Psi / 1/2" Female Npt Inlet & Outlet / Refrigerant Fluid Type: R134a / Wire Size Required: 14 Gauge / Dew Point: 41 Degrees Fahrenheit at 100 PSI / 115V Single Phase / Non-Cycling / 55 LBS Dryer Total Weight / 130 F Max Compressed air Inlet Temp / 113 F Max Ambient Temp / 225 PSI Max Inlet.
- Please Note: To Ensure Dryer Functionality, a Moisture Removing Filter with a Filtration Micron rating of 5u Micron or better should Always be Present Presceding Refrigerated Air Dryers. A Moisture Removing Filter Increases the Dryer's Efficiency and Prolongs the Lifespan of the Dryer.
- Advanced monitoring: Equipped with an electronic controller that digitally displays the temperature and dew point, providing real-time data for monitoring the dryer's performance. This controller also manages the timing for the drain valve and condenser fan operation.
- Please Ensure Your Air Compressor's CFM Flow Rate Is No Greater Than 20 CFM. Oversizing The Dryer To The Air Compressor Is Always Recommended. Undersizing The Dryer Will Cause Performance And Longevity Issues.
- Size: Dryer Only
